Rancho RS77256 - RS7MT Suspension Shock Absorber

Name: Rancho RS77256 - RS7MT Suspension Shock Absorber
Brand: Rancho
SKU: RCH-RS77256
Price: 77.99 USD
Availability: InStock

Write a Review

$85.79

$77.99

(You save $7.80 )

SKU: RCH-RS77256

UPC: 039703014618

Stock: 8

Vendor: Keystone - CSR

SpecialOrder: False

CarbRejected: True

CouponIsOn: False

StockEta: N/A

ProfitMargin: 13.500

CostOfItem: 55.95

ItemPopularity: 0

MapPrice: 0.00

RetailPrice: N/A

IsReturnable: True

WarehouseStock: 8

ShipperHq: {"shipping-groups":["Keystone","FreeShipping","Flatrate_Keystone","CarbRejected"],"shipping-origins":[],"shipping-dimensional-rules":[]}

Current Stock: 8

Quantity:

Adding to cart… The item has been added

Rancho RS77256 - RS7MT Suspension Shock Absorber

$85.79

$77.99

(You save $7.80 )

Description
Warranty Information

Description

Rancho - RS77256

Rancho RS7MT RS77256 Suspension Shock Absorber

Application tuned for precision on-road and off-road handling, Rancho® RS7MT® monotube shocks are highly effective in the dissipation of heat, making them ideal for extreme off-road use and larger wheel and tire packages. RS7MT shocks feature an integrated dirt wiper sealing system that keeps dirt and debris out, hardened piston rod that resists scuffs and corrosion plus an internal rebound bumper to smooth out your ride on any terrain.

PRECISE HANDLING AND PERFORMANCE -- Deflective Disc Valving features digressive, linear or progressive tuning based on application requirements for precision handling and performance on- and off-road
STRONG AND DURABLE -- Features a 14mm hardened chrome piston rod to resist scuffs & corrosion, double-welded loops at stress areas, double strength closure method and hot form reserve tube
HANDLES EXTREME TEMPERATURE CHANGES -- Large 2-in. monotube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
REDUCES FADE -- Full-floating dividing piston and high-pressure nitrogen gas maintains constant pressure against the hydraulic oil, reducing aeration and shock fade
SMOOTH PERFORMANCE -- Internal rebound bumper and shouldered rubber bushings help reduce noise, vibration and ride harshness while the PTFE-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
THE RIGHT FIT -- Designed to fit right out of the box, application-specific mounting installs easily with no need for installing sleeves or extra hardware
KEEPS DIRT AND DEBRIS OUT -- Sealing system with integrated dirt wiper helps keep moisture, dirt and debris from being ingested into the shock and contaminating the oil and destroying the internal seal
BUILT TO LAST -- Large 46mm fluon-banded piston for consistent sealing between the piston and monotube for precise control, ride and handling; for extra protection, purchase shock boot RS1952 or RS1961
BOLD APPEARANCE -- Black satin finish with distinctive Rancho red logo for an eye-catching look that stands out
BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty

Cylinder Outside Diameter: 50

Cylinder Outside Diameter: 1.96

Body Material: Steel

Cylinder Material: Steel

Body Color: Black

Cylinder Color: Black

Color: Black

Finish: Painted

Cylinder Finish: Painted

Boot Included: No

Dust Shield Included: No

Rod Diameter: 14

Rod Diameter: 0.55

Shaft Material: Chrome

Shock Absorber Bore Size: 46

Shock Absorber Bore Size: 1.81

Includes Bump Stop: No

Internal Rebound Bumper: Yes

Internal Rebound Spring: No

Hydraulic Lockout: No

Internal Construction Type: Single Tube

Grade Type: Performance

Type: Telescopic

Adjustable Damping: No

Active or Passive Suspension: Passive

Adjustable Compression: No

Adjustable Rebound: No

Valving Type: Progressive

Self-Leveling: No

Adjustable Ride Height: No

Air Adjustable: No

Air Ride Suspension: No

Bladder(s) Included: No

Bladder Sleeve(s) Included: No

Bladder Heavy Duty Crimping Rings Included: No

New Or Remanufactured: New

Coil Over Springs Included: No

Bearing Plate Included: No

Spring Included: No

Coil Spring Insulator(s) Included: No

Spring Isolators Included: No

Spring Seat Included: No

Remote Reservoir: No

Strut Mount Insulator(s) Included: No

Compressed Length: 398

Compressed Length: 15.67

Extended Length: 24.43

Extended Length: 620.6

Travel Length: 222.6

Travel Length: 8.76

Shock Stroke: 222.6

Shock Stroke: 8.76

Lower Mount Type: Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1 3/8" Sleeve OAL

Lower Mount Code: LS37

Upper Mount Type: Cross Pin Mount - Open Ended, 3/8" Hole ID (Both Ends) X 3 3/16" Pin Length (Hole Center to Center)

Upper Mount Code: XP12

Shock Absorber Rod End Measuring Point: Center of Mounting Hole

Shock Absorber Body End Measuring Point: Center of Loop

Gas Charged: Yes

Mounting Hardware Included: No

Body Diameter: 50

Body Diameter: 1.96
