Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front
Baer Brakes 4301597GB - Track4 Brake System Front

Baer Brakes 4301597GB - Track4 Brake System Front

Write a Review
$2,750.95
$2,444.95
(You save $306.00 )
SKU: HKMJ-4301597GB
UPC: 090127878149
Stock: 20
Vendor: Holley - CSR
SpecialOrder: False
CarbRejected: False
CouponIsOn: True
StockEta: N/A
ProfitMargin: 29.100
CostOfItem: 1646.90
ItemPopularity: 0
MapPrice: 2444.95
RetailPrice: 2750.95
WarehouseStock: 20
EbayAllowed: False
ShippingGroups: ["Flatrate_Holley"]
EbayPrice: 2109.95
ShipperHq: {"shipping-groups":["Holley","FreeShipping"],"shipping-origins":[],"shipping-dimensional-rules":[]}
IsReturnable: True
EbayPriority: 0
Adding to cart… The item has been added
  • screenshot-2024-06-06-013938.png
Baer Brakes 4301597GB - Track4 Brake System Front

Baer Brakes 4301597GB - Track4 Brake System Front

$2,750.95
$2,444.95
(You save $306.00 )
Description

Baer Brakes - 4301597GB

Baer Brakes 13" Track4 Front Brake Kit, Grabber Blue, SDZ

Fits 1960-87 Chevy/GMC 2WD 1/2 Ton Trucks w/Wilwood C10 Aluminum Modular Pro Spindles

The Track4 system comes with the 2-piece 4-piston, T4 caliper mounted to a 13", 1 piece slot, drill, zinc plated rotor. The T4 caliper has D.O.T compliant dust and weather seals and uses the popular D0749 pad type. All mounting brackets, stainless braided hoses and hardware are also included. The 13" Track4 is designed to fit most 17” or larger wheels.

  • 2-Piece, 4-Piston, T4 Caliper Manufactured in Phoenix, AZ
  • CNC Machined from US Sourced Forged or Billet Aluminum
  • Powder Coated Finish
  • Stainless Steel Pistons, Abutments and Noise Suppression Clips
  • Staggered Pistons to Minimize Uneven Pad Wear
  • Dual Seals, Dust/Weather & Pressure
  • 1-Piece Slot, Drilled, Zinc-Plate Rotor

Applications: GM C10 Trucks 60-87
Axle: Front
Brand: Baer Brakes
Caliper: T4
Caliper Color: Grabber Blue
Category: Brake
Disc Brake Caliper (Front) Piston Quantity: 4
Disc Brake Caliper (Front) Type: Fixed
Disc Brake Pad FMSI Number: D0749
Disc Brake Rotor (Front) Construction: Vented
Disc Brake Rotor (Front) Outside Diameter: 13.000
Emission Code: 6
Export Description: Brake Components
Fitment Notes: w/Wilwood C10 Aluminum Modular Pro Spindles
Grade Type: Performance
Hose Material: Stainless Steel
Lug Count: 5 Lug
Min Wheel Dia (verify using template): 17
part type: Disc Brake Upgrade Kit
Product Line: 13 Inch Track4
Product Type: 13 Inch Track 4 Front Brake Kit
Rotor Thickness: 1.100
Rotor Type: 1-Piece
Spindle Type: Wilwood C10 Alum Modular Pro
Spindles Included: No
Sub Category: Service Kits
Surface Type: Slotted, Drilled & Zinc Plated
System Notes: Fits Wilwood C10 Aluminum Modular Pro hub pack spindles. Bolt on hub packs not included (Does NOT fit CPP X10 Spindle)
Template: Q082H
Wheel Lug/Bolt Pattern: 5x5.00

Warranty Information
