Baer Brakes 4301390FR - Extreme+ Brake System Front

Baer Brakes 4301390FR - Extreme+ Brake System Front

Name: Baer Brakes 4301390FR - Extreme+ Brake System Front
Brand: Baer Brakes
SKU: HKMJ-4301390FR
Price: 4444.95 USD
Availability: InStock

Write a Review

$5,000.95

$4,444.95

(You save $556.00 )

SKU: HKMJ-4301390FR

UPC: 090127876411

Stock: 20

Vendor: Holley - CSR

SpecialOrder: False

CarbRejected: False

CouponIsOn: True

StockEta: N/A

ProfitMargin: 31.100

CostOfItem: 2985.90

ItemPopularity: 0

MapPrice: 4444.95

RetailPrice: 5000.95

WarehouseStock: 20

EbayAllowed: False

ShippingGroups: ["Flatrate_Holley"]

EbayPrice: 3909.95

ShipperHq: {"shipping-groups":["Holley","FreeShipping"],"shipping-origins":[],"shipping-dimensional-rules":[]}

IsReturnable: True

EbayPriority: 0

Current Stock: 20

Quantity:

Adding to cart… The item has been added

Baer Brakes 4301390FR - Extreme+ Brake System Front

$5,000.95

$4,444.95

(You save $556.00 )

Description
Warranty Information

Description

Baer Brakes - 4301390FR

Baer Brakes 14" Extreme+ Front Brake Kit, Fire Red, SDZ, Std. Studs

Fits 1960-87 Chevy/GMC 2WD 1/2 Ton Trucks w/CPP Nodular Iron 2.5" Drop Spindle (5 Lug, 5x5"BC)

The Extreme+ system comes with the 1-piece Monoblock 6-piston, 6S caliper mounted to a 14", 2 piece slot, drill, zinc plated rotor. The 6S caliper is fully machined in Phoenix, AZ from a US sourced 2618 Aluminum forging, includes stainless steel pistons and abutments, D.O.T. compliant dust and weather seals and uses the popular D1247 pad type. Rotors are pre-assembled with NAS high grade stainless hardware. Billet aluminum hubs come assembled with premium bearings packed with Redline synthetic grease and billet dust caps. All mounting brackets, stainless braided hoses and hardware are also included. The 14” Extreme+ fits most 18” or larger wheels.

1-Piece Monoblock, 6-Piston, 6S Caliper Manufactured in Phoenix, AZ
CNC Machined from US Sourced 2618 Aluminum Forging
Powder Coated Finish
Stainless Steel Pistons, Abutments and Noise Suppression Clips
Staggered Pistons to Minimize Uneven Pad Wear
Dual Seals, Dust/Weather & Pressure
2-Piece Slot, Drilled, Zinc-Plate Rotor w/Billet Aluminum Hat

Applications: GM C10 Trucks 60-87

Axle: Front

Brand: Baer Brakes

Caliper: 6S

Caliper Color: Fire Red

Category: Brake

Disc Brake Caliper (Front) Piston Quantity: 6

Disc Brake Caliper (Front) Type: Fixed

Disc Brake Pad FMSI Number: D1247

Disc Brake Rotor (Front) Construction: Vented

Disc Brake Rotor (Front) Outside Diameter: 14.000

Emission Code: 6

Export Description: Brake Components

Fitment Notes: w/CPP 2.5 inch Drop Modular Spindle (5 Lug, 5x5BC)

Grade Type: Performance

Hose Material: Stainless Steel

Lug Count: 5 Lug

Min Wheel Dia (verify using template): 18

part type: Disc Brake Upgrade Kit

Product Line: 14 Inch Extreme+

Product Type: 14 Inch Extreme+ Front Brake Kit

Rotor Thickness: 1.250

Rotor Type: 2-Piece

Spindle Type: CPP Nodular Iron 2.5" Drop Spindles

Spindles Included: No

Sub Category: Service Kits

Surface Type: Slotted, Drilled & Zinc Plated

System Notes: Fits CPP 2.5" nodular drop spindles: CP30106-1 (1960-1962 C10), CP30106-2 (1963-1970 C10), CP30106-3 (1971-1972 C10) or CP30106-4 (1973-1987 C10)

Template: N117P

Wheel Lug/Bolt Pattern: 5x5.00

Wheel Stud Size: 1/2-20 x 2.25 inch

Warranty Information
